Input Ports

Tag

Connect a (Hair) Selection Tag's Object output port to this port.

On

This is a Boolean value that will turn the Node on or off.

Output Ports

Iteration[-2147483648..2147483647]

This output port can, for example, be connected with a Hair Point Node's Index input port. Index numbers of guide points, hair points or of guides, will be output.

The setup shown below sets all guide or hair points in the Selection tag to a mass of 0.

Count[-2147483648..2147483647]

This port outputs the number of elements selected.
